Key Specifications
- Print Method: Thermal Transfer & Direct Thermal
- Resolution: 203 dpi (8 dots/mm) / Optional 300 dpi & 600 dpi
- Max Print Speed: 356 mm per second (14″ ips)
- Max Print Width: 104 mm (4.09″)
- Max Print Length: 3,988 mm (at 203 dpi)
- Memory: 256 MB RAM; 512 MB Flash
- Connectivity: USB 2.0, RS-232 Serial, 10/100 Ethernet, Bluetooth 2.1, USB Host
Media & Ribbon Characteristics
- Media Types: Continuous, die-cut, notch, black-mark
- Media Width: 25.4 mm to 114 mm (Tear/Cutter)
- Max Media Roll Size: 203 mm O.D. on a 76 mm I.D. core
- Ribbon Standard Length: 450 meters (1,476′)
- Ribbon Width: 51 mm to 110 mm
- Ribbon Setup: Ribbon wound ink-side out (Ink-side in supported with optional spindle)
Physical Characteristics
- Dimensions: 269 mm (W) x 324 mm (H) x 495 mm (D)
- Weight: 16.33 kg (36 lbs)
- Construction: Metal frame and bi-fold metal media cover with enlarged viewing window
6 Month Warranty
